48v 105ah lithium battery

This 48V 105Ah LiFePO₄ lithium battery is a high-performance energy solution designed for a wide range of 48V electric mobility and industrial applications. It delivers stable output, high energy density, and long service life for both commercial and fleet use.

Built with an IP67-rated enclosure, advanced battery management system, and optional Bluetooth monitoring, this battery is engineered for reliable operation in demanding outdoor and industrial environments.

51.2V 105Ah (5.37kWh) LiFePO₄ lithium battery pack
IP67 waterproof & dustproof enclosure for outdoor use
Smart BMS with comprehensive protection functions
Bluetooth APP monitoring available as an option
Stable and efficient power output for continuous operation
Suitable for electric vehicles, utility carts, industrial equipment & light EV systems

BATTERY QUICK FACTS

🔌

INTERFACE DESCRIPTION

The battery pack is equipped with clearly defined terminals and communication ports:

Positive & negative power terminals
Charging port
Communication / display interface
Status indicator

(Detailed interface layout available upon request)

🔗

COMMUNICATION & EXPANSION

Clearly defined interfaces for system integration and expansion:

Communication / display interface
External device connection support
Expandable monitoring & control options

(Interface configuration depends on system requirements)

📄

CERTIFICATIONS & COMPLIANCE

UN38.3
CE
FCC
RoHS

(Full certification documents available upon request)

🛡️

IP67 PROTECTION – OUTDOOR READY

Fully waterproof, rainproof, and dustproof
Sealed aluminum housing with pressure relief design
Suitable for wet, dusty, and uneven terrains

📡

SMART FEATURES & OPTIONAL FUNCTIONS

Bluetooth APP Monitoring
Real-time battery status (SOC, voltage, current, alarms)

SOC Display & Buzzer Alarm
Clear status indication and low-SOC warning

Low-Temperature Heating (Optional)
Supports charging in cold environments

Parallel Connection Support
Expand system capacity for specific applications

GPS Tracking (Optional)
Customized GPS positioning for fleet management

Technical Specifications – Model TC105
Electrical Specifications
Nominal Voltage	51.2V
Nominal Capacity	105Ah
Nominal Energy	5376Wh
Cell Chemistry	LiFePO₄
Cell Type	Prismatic aluminum shell
Cycle Life	≥3000 cycles @ 80% DOD
Discharge Specifications
Continuous Discharge Current	105A
Peak Discharge Current	315A (30s)
BMS Options	150A / 200A / 250A / 300A (optional)
Mechanical Specifications
Dimensions (L × W × H)	530 × 330 × 255 mm
Weight	Approx. 53 kg
IP Rating	IP67

Applications >>

Application Scenario

Golf Cart

Designed to deliver stable and efficient power for golf carts operating in resorts, campuses, and commercial environments.
The 48V 105Ah lithium battery provides reliable energy output, weather-resistant protection, and flexible monitoring options for daily operation.
